SPA/SPK/SPT Series Scissor Lift Table
Scissor Lift Table
SPA/SPK/SPT series
Load Capacity: 350kgs
Max.Lift Height: 1320mm
- 24-Hour Online Support
- Global Service Network
- Technical Solutions
- Specifications
- 3D VIEW
| SPA/SPK/SPT LIFT TABLE SPECIFICATION | ||||||||||
| Specification | 1 | Model | SPA150 | SPA300/500 | SPA1000 | SPA1500 | SPK1000 | SPT500 | ||
| 2 | Capacity | kg | 150 | 300/500 | 1000 | 1500 | 1000 | 500 | ||
| 3 | Max. lift height | h12(mm) | 740 | 900 | 1000 | 1000 | 1000 | 900 | ||
| 4 | Min. height of table | h13(mm) | 225 | 340 | 420 | 420 | 425 | 310 | ||
| 5 | Lifting height | h3(mm) | 515 | 560 | 580 | 580 | 575 | 590 | ||
| 6 | Table size | l x b5 x s(mm) | 740×450×35 | 855×500×50 | 1000×510×55 | 1220×610×60 | 1200×800×55 | 1600×800×50 | ||
| 7 | Foot pedal cycles to max height | <=25 | <=32/<=45 | <=55 | <=70 | <=55 | <=55 | |||
| 8 | Service weight | kg | 44 | 82/87 | 115 | 135 | 135 | 135 | ||
| 9 | Carton size | mm | 860×485×300 | 985×510×350 | 1170×520×420 | 1420×625×420 | 1420×810×430 | 1800×810×320 | ||
| 10 | Total height | h14(mm) | 922 | 970 | 996 | 962 | 1130 | 970 | ||
| 11 | Tyre size | d(mm) | ￠100 | ￠127 | ￠150 | ￠150 | ￠150 | ￠127 | ||
